VAAST Bikes HongKong

R/1 Frameset

R/1 Frameset

HK$12,800.00
HK$12,800.00
Sale Sold out
Size
The aerodynamic R/1 road bike has been optimized for design - with speed, aerodynamics, weight and agility in mind. Weighing only 1250 grams, the Allite Super Magnesium? frame offers a weight and performance ratio unmatched by other metal frames, and is built with road geometry for a perfect fit no matter the size of the rider.Utilize VAAST V-Fit parameters for comfort and control, and the head tube and seat tube angles have been engineered to give you a confident ride and good tracking when turning.Unlike our acclaimed gravel road bike, the A/1, the R/1 tube shape has been reimagined to take advantage of super magnesium alloys and Compared with the traditional cylindrical tubular metal frame, the aerodynamic performance is optimized by 30%.In addition, it also provides enough tire clearance to fit tires up to 30mm, or 25/28mm wide when fitted with fenders.All these advantages, combined with carbon fiber wheels, and an exclusive carbon fiber fork and seat tube, make it a road ride that is enough to take you in the wind.

Lightweight, aerodynamic, fast¡Xthis is the all-new VAAST Model R/1.
View full details

R/1 車架組 尺寸與規格

R/1 sizing chart

?SIZAND XS S M L XL XXL
suitable Height (cm) 155-163 160-170 167-177 174-184 180-188 188-196
E RANDACH 365 370 380 388 400 413
F STACK 500 510 540 565 590 610
H WHEELBASE 973 973 988 990 1009 1029
I CHAINSTAY Length 410 410 410 410 410 410
J FRONT CENTER 575 575 591 590 610 629
K BB DROP 75 75 72 72 69 69
L BB Height 269 269 272 272 275 275
M SEAT TINBE angle 75.5 74.5 73.5 73 73 73
N HEAD TINBE angle 70.5 71.5 72 73 73 73
U SEAT TINBE Length 470 500 520 540 560 580
G TOP TINBE Length (horizontal) 494 511 540 561 580 600
P HEAD TINBE Length 94 101 129 153 183 204
Q STANDOVER Height 722 742 766 788 812 832
FORK RAKE/offset 52 52 52 45 45 45
FORK Length full 375 375 375 375 375 375
T TRAIL 58.6 58.6 55.5 56.6 56.6 56.6
SEATPOST Length 300 300 350 350 350 350
CRANK Length 165 170 172.5 172.5 175 175
B STEM Length: Force AXS 90 90 105 105 120 120
B STEM Legnth: Ultegra, 105 70 90 100 100 120 120
HANDLEBAR Width: Force AXS 400 400 420 420 440 440
TRADABLE Width: Ultegra, 105 380 400 420 420 440 440

?

?

?

R/1 車架組規格表

Components Part
frame? Frame Road 700c disc, AE81 SuperMag, VAAST Road geometry, internal cable routing, fender ready. Up to 30mm tire clearance
frame weight Frame Weight 1250g
front fork Fork VAAST Road full-carbon disc. Up to 30mm tire clearance
Maximum tire width Max Tire Clearance 30mm
axle Axles VAAST M12 w/Removable lever
Seatpost Seat Post VAAST Carbon fiber, (300mm 49/52, 350mm 54/56/58/60)

A RIDE FEEL LIKE NO OTHER

VAAST Bikes is the first to use ALLITE? SUPER MAGNESIUM?, a true innovation in material science. This high-strength alloy features excellent shock absorption properties, weighs 33% less than Aluminum and 50% less than Titanium by volume, and is significantly stronger than both. Through the exclusive use of this eco-friendly metal, we have achieved a ride that feels like no other.

COMMITTED TO A VIBRANT CYCLING ECOLOGY

From the beginning we¡¦ve been inspired to promote the responsible use of materials and responsible riding in all its forms.

Our frames are more sustainably made and they¡¦re 100% recyclable. We were also the first bike brand to use 100% fiber-based, plastic-free packaging.
