Y/1 24" (Demo) - 1pcs @V Bike
Y/1 24" (Demo) - 1pcs @V Bike
Regular price
$30,000.00 TWD
Regular price
Sale price
$30,000.00 TWD
Unit price
per
Couldn't load pickup availability
The Y/1 Mountain 24" is designed for young riders and athletes.Legal 1X drivetrain,
High-performance suspension and long, slack geometry allow the bike to perform like an adult performance model on a variety of terrains.
Lightweight components throughout and tailored dimensions make it one of the best performing products on the market.
It's perfect for enthusiasts ages 8 and up and parents who want their kids to have the same opportunities to enjoy their own adventures.
Y/1 24" sizing chart & spec sheet
Y/1 sizing chart
| Y/1 | 20 | 24 |
| REACH | 310 | 357 |
| STACK | 457 | 522 |
| TOP TUBE LENGTH, HORIZONTAL | 459 | 527 |
| WHEELBASE | 895 | 1005 |
| CHAINSTAY LENGTH | 350 | 410 |
| FRONT CENTER | 546 | 598 |
| BB DROP | 20 | 35 |
| BB HEIGHT | 270 | 268 |
| SEAT TUBE ANGLE | 72 | 72 |
| HEAD TUBE ANGLE | 68 | 68 |
| SEAT TUBE LENGTH | 265 | 310 |
| HEAD TUBE LENGTH | 140 | 150 |
| STANDOVER HEIGHT | 567 | 616 |
| FORK RAKE/OFFSET | 40 | 40 |
| FORK LENGTH, FULL | 390 | 390 |
| TRAIL | 56 | 75 |
| SEAT TUBE LENGTH INCHES | 10.6 | 12.4 |
| RECOMMENDED RIDER HEIGHT | ||
| TRUE REACH (6 deg, 20 mm spacer, 25 mm half stem) | 353 | 400 |
| TRUE STACK (6 deg, 20 mm spacer, 25 mm half stem) | 505 | 570 |
| CRANK LENGTH | 152 | 152 |
| STEM LENGTH | 50 | 50 |
| SEATPOST LENGTH | 300 | 300 |
| HANDLEBAR WIDTH | 560 | 560 |
Y/1 24" spec sheet
| Frame | Youth MTB 24" AE81 ALLITE Super Mag - w/ replaceable hanger |
|---|---|
| Fork | SunTour 24" XCR Air with lockout |
| Tires | Kenda Small Block Eight - 24" x 1.95" |
| Rims | Alex MD19 24" double wall aluminum - 28H - Presta Valve |
| Rotors | Promax 160mm F & R |
| Crank | Forged Alloy - 32T |
| Cassette | SunRace - 11/42T - 10-speed |
| Shifters | Shimano Deore - RapidFire Plus - 10-speed |
| RD | Shimano RD-M6000 10-speed |
| Chain | KMC X10 |
| Brakes | Promax Hydraulic disc brakes w/Youth designed lever |
| Bottom Bracket | VP Components - sealed cartridge bearing |
| Hub F | Forged alloy MTB - 6-bolt disc - QR - 28H |
| Hub R | Forged alloy MTB cassette - 6-bolt disc - QR - 28H |
| Spokes | 14g stainless |
| Axles | QR F & R |
| Handlebar | VAAST MTB Youth - 6061 aluminum - 560mm width |
| Stem | VAAST 3D forged |
| Grips / Tape | VAAST Dual Density |
| Seat Post | VAAST Micro adjust aluminum - 27.2mm x 300mm |
| Saddle | VAAST Youth Sport |
| Bike weight | 10.6kg |
LIGHTER, STIFFER, PROFOUNDLY BETTER.
VAAST Bikes is the first to use ALLITE? SUPER MAGNESIUM?, a true innovation in material science. This high-strength alloy features excellent shock absorption properties, weighs 33% less than Aluminum and 50% less than Titanium by volume, and is significantly stronger than both. Through the exclusive use of this eco-friendly metal, we have achieved a ride that feels like no other.
